Spray Type Container Washing Machine
The Spray Type Container Washing Machine is an automatic cleaning machine with high performance to clean the inside of removable containers. It can effectively control the emission of the cleaning liquid and residue, and also can reduce labor intensity and save labor cost. Exproof configuration and Non Exproof configuration are for option. With specially designed cleaning head, it can do automatic thorough cleaning of the high viscosity materials in the container such as paint, ink and adhesive etc. For water-based materials with weak adhesion such as high viscosity coatings or putty, high-pressure flushing type washing machine can be customized.
Product Overview
| Materials Viscosity | ≤5,000,000 cps |
| Production Capacity |
100-4,000L
|
| Application Industry | Suitable for cleaning mixing containers in industries such as coating, putty, ink, adhesive, energy, electronics & electrical appliances, pharmaceuticals, cosmetics, food etc. (For more application industry, please click “Free Consultation”) |
| Applicable Materials | Various slurries with viscosity less than 5,000,000cps, solid content under 90% such as battery paste, solder paste, ceramic paste, silicone inks, sealants, structural adhesives, soft cream, jam and other more than 1,000 kinds of materials. |
Working principle
Move the barrel to the working area of the barrel washer, the working head of the barrel washer is raised, moved into the tank and fixed, and the automatic cleaning program is started; The motor or air motor drives the automatic retractable multi-group cleaning brush to rotate, and during the rotation process, the cleaning head is always firmly attached to the inner wall of the mixing drum, and there is an automatic circulating spray device to clean the drum; It can be equipped with a filtration device to allow solvent reuse.
Product Advantages
-
Safe and convenient operation
Adopt hydraulic cylinder or Pneumatic cylinder as lifting actuators. Control the washing head (washing lid) up, stop and down through controlling the valve, simple operation with high stability; with barrel holding device for fixing the mixing tank rapidly to prevent any possible accident due to tank displacement. Interlock between the tank in place and machine running can be set to avoid mal-operation.
-
High durability, wide application
The washing head adopts corrosion-resistant copper brush/ nylon brush/ animal bristle, the cleaning nozzle is flexible and Stretchable, can be applied to containers with different specifications from 100L to 4000L in one machine (washable barrel diameter range areas: Ф600-Ф1800mm)
-
High automation level
All procedures (up and down, stretchable adjustment of the copper brush, automatic cleaning, time setting, reciprocating) can be controlled by control panel/ PLC, so that only need one person to do the whole washing work.
Related Video
Technical Parameter
| Model | Container Dia. Range
(mm) |
Container Height Range
(mm) |
Main motor Power
(kw) |
Cleaning Speed
（rpm） |
Hydraulic power
（kw） |
Lifting stroke
(mm) |
Cleaning fluid interface |
| SXTS-A | 600-1000 | 500-900 | 5.5 | 0-160 | 1.1 | 1100 | DN25 |
| SXTS-B | 800-1200 | 700-1000 | 11 | 0-120 | 2.2 | 1200 | DN32 |
| SXTS-C | 1000-1450 | 850-1300 | 15 | 0-100 | 2.2 | 1500 | DN40 |
| SXTS-D | 1200-1800 | 950-1600 | 22 | 0-85 | 4 | 1800 | DN50 |
